Toughened Laminated Glass

Available for Online Ordering

Our Toughened Laminate Glass is now available for Online Ordering and Delivery Nationwide. Simply select a shape from below to begin.

Square / Rectangle

Order upto a maximum size of 3200mm x 1600mm.

Circle

Order a Circle upto a maximum size of 2000mm Diameter.

Parallelogram

Order upto a maximum size of 3200mm x 1600mm.

Irregular Shape

Provide us with a template / drawing to follow.

About the Product

Our Toughened Laminate is made from multiple layers of Toughened glass, laminated together using an EVA interlayer. One of the fundamental benefits to multiple layers of glass being laminated together is that, should one panel break, the additional intact panel will still be in position while keeping hold of the broken pieces. Even in the event that all of the glass panels were to break, the interlayer adheres so strongly to the glass everything is held together.

We can produce Laminate in any combination of Toughened or Non-Toughened glass, catering for any specification required.

We are able to laminate up to a maximum overall thickness of 80mm.

Interlayers are available in a range of different colours and provides the possibility to have images such as logos, textile fabrics and frosted effects within the center of the glass.

Toughened Laminate is ideal for Balustrading, Doors, Partitions and Flooring as it is a Safety Glass and is commonly required in current building regulations.

Crackle Effect Glass / Shatterlam

Crackle Effect, also known as Shatterlam, is created by laminating 3 layers of glass together and breaking the centre pane.

To achieve this effect the centre pane must be toughened, however the Upper and Lower panel can be of any desired glass type, toughened or annealed.

Mirror can also be used as the rear / underside / lower pane to add a reflection making Crackle Effect glass suitable as wall panels, table tops and worktops.

All shapes are available along with cutouts and holes making this product suitable for a wide range of applications.

close up photo of crackle effect glass - also known as crackle effect

Switchable Privacy Glass

Using a special interlayer we can produce glass that can switch from Opaque to Transparent at the touch of a button, providing privacy when its needed. This glass is ideal for environments such as Office Conference rooms or an alternative use could be Showrooms / Shops where valuable products need to be kept out of sight during closed hours.

Both Partitions and Doors are available in swithable privacy glass.

switchable privacy glass shown on and off

Want a Quotation for Toughened Laminate or Switchable Glass?

We offer a full Templating and Fitting Service for all of our products, if this is something you are interested in please Get In Touch detailing your requirements.

Alternatively you can order Toughened Laminate or Switchable Glass using our Online Shop, which is able to both provide instant quotations and process payments.

Effects

Laminating multiple layers of glass together opens up many new design possibilites, as we can insert layers of materials or films with effects between the layers of glass.

By having three layers or more, Crackle Effect Glass (also known as Shatter Lam) becomes possible. This is usually achieved by laminating a Toughened panel inbetween other glass layers, then breaking the Toughened center layer. An interesting variation on this is to have the lower layer made from Mirror, reflecting up through all of the layers, creating a Crackled Mirror effect

Leadtime / Turnaround

As we have to manufacture multiple panels of glass to produce a single Laminated Panel, we require a 15 day Working Day lead time on all Toughened Laminate and Switchable Glass products.

Bespoke Products

We offer a Template, Manufacture & Fit service to ensure you get the perfect glass installation.
