Glass Shelving clips suitable for 8mm / 10mm Glass
Screws Not Included
For each edge to have a clip fitted, the Glass size must have 5mm deducted per side to allow for the additional space taken by the clip. See the below arrangement examples for further information.
Arrangement A shows clips fitted to each end of the shelf. If the overall size measures 1000mm with an enclosed area, the glass should measure 990mm.
Arrangement B shows clips fitted to the back edge of the shelf only. If the overall depth measures 300mm with an enclosed area, the glass should measure 295mm.
